序号 |
测试项目 |
样品数/批 |
批数 |
测试方法 |
1 |
Pre- and Post- Stress Electrical Test |
所有提交认证的产品 |
用户规范 |
3 |
High Temperature Exposure (Storage) |
77 Note B |
1 |
MIL-STD- 202 Method 108 |
4 |
Temperature Cycling |
77 Note B |
1 |
JESD22 Method JA-104 |
5 |
Destructive Physical Analysis |
10 Note B |
1 |
EIA-469 |
6 |
Moisture Resistance |
77 Note B |
1 |
MIL-STD- 202 Method 106 |
7 |
Biased Humidity |
77 Note B |
1 |
MIL-STD- 202 Method 103 |
8 |
Operational Life |
77 Note B |
1 |
MIL-STD-202 Method 108、MIL-PRF- 27 |
9 |
External Visual |
所有提交认证的产品 |
MIL-STD- 883 Method 2009 |
10 |
Physical Dimension |
30 |
1 |
JESD22 Method JB-100 |
11 |
Terminal Strength (Leaded) |
30 |
1 |
MIL-STD- 202 Method 211 |
12 |
Resistance to Solvents |
5 |
1 |
MIL-STD-202 Method 215 |
13 |
Mechanical Shock |
30 Note B |
1 |
MIL-STD- 202 Method 213 |
14 |
Vibration |
30 Note B |
1 |
MIL-STD-202 Method 204 |
15 |
Resistance to Soldering Heat |
30 |
1 |
MIL-STD-202 Method 210 |
16 |
Thermal Shock |
30 |
1 |
MIL-STD-202 Method 107 |
17 |
ESD |
15 |
1 |
AEC-Q200-002 or ISO/DIS 10605 |
18 |
Solderability |
15 each condition |
1 |
J-STD-002 |
19 |
Electrical Characterization |
30 Note A |
3 |
用户规范 |
20 |
Flammability |
/ |
/ |
UL-94 |
21 |
Board Flex |
30 |
1 |
AEC-Q200-005 |
22 |
Terminal Strength (SMD) |
30 |
1 |
AEC-Q200- 006 |
23 |
Beam Load Test |
30 |
1 |
AEC-Q200- 003 |
24 |
Flame Retardance |
30 |
1 |
AEC-Q200-001 |
25 |
Rotation Life |
30 |
1 |
MIL-STD-202 Method 206 |
27 |
Surge Voltage |
30 |
1 |
JIS-C-5101- 1 |
29 |
Salt Spray |
30 |
1 |
MIL-STD-202 Method 101 |
30 |
Electrical Transient Conduction |
30 |
1 |
ISO-7637-1 |
31 |
Shear Strength |
30 |
1 |
AEC-Q200-004 |
32 |
Short Circuit Fault Current Durability |
30 |
1 |
AEC-Q200-004 |
33 |
Fault Current Durability |
30 |
1 |
AEC-Q200-004 |
34 |
End-of-life Mode verification |
30 |
1 |
AEC-Q200-004 |
35 |
Jump Start Endurance |
30 |
1 |
AEC-Q200-004 |
36 |
Load Dump Endurance |
30 |
1 |
AEC-Q200-004 |
